Eltex ME5200 [72/670] Aaa authentication enable
![Eltex ME5200 [72/670] Aaa authentication enable](/views2/1569351/page72/bg48.png)
серверы.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
0/ME5100:example_router01(config)# aaa accounting login start-stop radius
0/ME5100:example_router01(config)# aaa accounting login start-stop tacacs
NOTE
Параметры radius и tacacs не являются взаимоисключающими, учет может
производиться путем обоих методов.
5.3. aaa authentication enable
Данная команда создает в конфигурации устройства именованный список методов,
используемых для enable-аутентификации (аутентификации процесса повышения
привилегий) и позволяет перейти в режим настройки этого списка (config-aaa-
authentication-enable).
Список методов, в сконфигурированной последовательности, будет применен при
выполнении enable-аутентификации. Переход к следующему методу списка осуществляется
только при невозможности воспользоваться предыдущим методом (например, в случае
недоступности AAA-сервера, на который ссылается метод). Если при проверке метода будет
получен четкий отказ от соответствующего источника (например, RADIUS Access-reject), то
аутентификация будет считаться неудавшейся и перехода к следующему методу
производиться не будет.
Отрицательная форма команды удаляет соответствующий именованный список методов.
Синтаксис
[no] aaa authentication enable LISTNAME
Параметры
• LISTNAME — имя списка методов.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
51
