![Eltex ME5200 [110/670] Severity](/views2/1569351/page110/bg6e.png)
Синтаксис
logging monitor { alert | crit | debug | emerg | error | info | none | notice | warning }
no logging monitor
Параметры
В качестве аргументов данной команды используются зарезервированные ключевые
слова, обозначающие уровни критичности. Указание ключевого слова none отключает
отображение любых сообщений в сессиях удаленного управления устройством.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# logging monitor warning
IMPORTANT
Не рекомендуется устанавливать низкие уровни важности (ниже
notice(5)) для отображения на удаленных подключениях, так как при
большом потоке сообщений управление устройством может оказаться
затрудненным.
7.11. severity
Данная команда задает минимальную степень важности (severity) сообщений,
отправляемых на удаленный сервер журналирования. Команда выполняется в режиме
настройки сервера журналирования.
Заданная степень важности используется в качестве фильтра — все системные события,
имеющие важность равную или более высокую, чем заданная, подлежат отправке на
удаленный сервер.
Согласно RFC3164 имеются следующие стандартные значения степеней важности:
Ê Numerical Severity
Ê Code
Ê 0 Emergency: system is unusable
Ê 1 Alert: action must be taken immediately
Ê 2 Critical: critical conditions
Ê 3 Error: error conditions
Ê 4 Warning: warning conditions
Ê 5 Notice: normal but significant condition
Ê 6 Informational: informational messages
Ê 7 Debug: debug-level messages
