Eltex ME5200 [526/670] Rate limit profile
![Eltex ME5200 [526/670] Rate limit profile](/views2/1569351/page526/bg20e.png)
Синтаксис
rate KBPS
no rate
Параметры
• KBPS — полоса пропускания в килобитах в секунду (1..4294967295)
Необходимый уровень привилегий
p10
Командный режим
config-qos-rate-limit-profile
config-qos-shape-profile
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# rate-limit profile 10Mbit
0/ME5100:example_router01(config-profile)# rate 10240
0/ME5100:example_router01(config-profile)#
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# shape profile 20Mbit
0/ME5100:example_router01(config-profile)# rate 20480
0/ME5100:example_router01(config-profile)# burst 10240
0/ME5100:example_router01(config-profile)#
23.19. rate-limit profile
Команда создает именованный профиль ограничения полосы пропускания трафика и
переходит к вводу дополнительных параметров.
Отрицательная форма команды удаляет профиль и все вложенные настройки.
Синтаксис
[no] rate-limit profile PROFILE_NAME
Параметры
• PROFILE_NAME — строковое имя профиля (1..63)
Необходимый уровень привилегий
p10
Командный режим
config-qos
