![Eltex ME5200 [360/670] Ip extcommunity](/views2/1569351/page360/bg168.png)
Командный режим
config
Пример
0/ME5100:example_router01(config)# ip-community TestCommList
0/ME5100:example_router01(config-ip-community)#
13.102.5. ip-extcommunity
Команда создает именованный список BGP extended community и входит в режим его
конфигурирования.
Отрицательная форма команды удаляет список.
Синтаксис
[no] ip-extcommunity EXTCOMMLIST
Параметры
• EXTCOMMLIST — имя списка extended community (1..32)
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# ip-community TestExtCommList
0/ME5100:example_router01(config-ip-community)#
13.102.6. le
Команда задает максимальную длину префикса.
Отрицательная форма команды удаляет значение.
Синтаксис
le INTEGER
no le
Параметры
• INTERGER — длина префикса в битах (0..128)
Необходимый уровень привилегий
p10
339
