• ospf-intra-area;
• ospf-type1-external;
• ospf-type1-nssa;
• ospf-type2-external;
• ospf-type2-nssa;
• static
Необходимый уровень привилегий
p10
Командный режим
config-router-static-destination-interface
Пример
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# destination 40.10.0.0/16 40.10.0.1
0/ME5100:example_router01(config-destination)# interface tengigabitethernet 0/0/7
0/ME5100:example_router01(config-tengigabitethernet)# path-type i3-connected
0/ME5100:example_router01(config-tengigabitethernet)#
10.7. router static
Включение поддержки статической маршрутизации и переход в режим настройки
статических маршрутов.
Отрицательная форма команды удаляет все статические маршруты в vrf default.
Синтаксис
[no] router static
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
configure
Пример
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)#
127
