Синтаксис
[no] user USERNAME
Параметры
• USERNAME — имя учетной записи. Имя может содержать строчные буквы латинского
алфавита, содержать арабские цифры, знаки дефиса и подчеркивания и иметь длину
не более 32 символов. Имя должно начинаться со строчной буквы латинского
алфавита.
Командный режим
config
Пример
0/ME5100:example_router01(config)# user vasily
0/ME5100:example_router01(config-user)#
73
