Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show system environment
Mon May 8 15:22:51 2017
Ê Hardware environment information for chassis 0
Ê Main system module is: ME5100
Ê CPU temperature (int/ext): 23 C / 26 C
Ê Switching engine temperature (int/ext): 23 C / 30 C
Ê Lookup engine temperature (int/ext): 22 C / 29 C
Ê Board sensor (inlet) temperature: 22 C
Ê System fan speed is set to 30%
Ê Current fan speeds:
Ê Fan 1: 4080 RPM
Ê Fan 2: 3660 RPM
Ê Fan 3: 3720 RPM
Ê Power supply 1 fan speed is 9240 RPM
Ê Power supply 2 fan speed is not present
2.18. show system inventory
Данной командой осуществляется просмотр информации об имеющихся в маршрутизаторе
компонентах, их типах, номерах аппаратных ревизий и серийных номерах.
Синтаксис
show system inventory
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
20
