Синтаксис
vfi STRING
no vfi
Параметры
• STRING — имя VFI, (1..16).
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# vfi test
0/ME5100:example_router01(config-vfi)#
417
