![Eltex ME5200 [454/670] Rx interval](/views2/1569351/page454/bg1c6.png)
Командный режим
config-bfd-session
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)# multiplier 3
0/ME5100:example_router01(config-session)#
17.6. rx-interval
Данная команда позволяет установить таймер для приема BFD Control пакетов.
Отрицательная форма команды возвращает значение по умолчанию (100).
Синтаксис
rx-interval NUMBER
no rx-interval
Параметры
• NUMBER (3-30000) — значение таймера в миллисекундах.
Необходимый уровень привилегий
p10
Командный режим
config-bfd-session
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)# rx-interval 500
0/ME5100:example_router01(config-session)#
17.7. tx-interval
Данная команда позволяет установить таймер для передачи BFD Control пакетов.
Отрицательная форма команды возвращает значение по умолчанию (100).
Синтаксис
tx-interval NUMBER
no tx-interval
Параметры
• NUMBER (3-30000) — значение таймера в миллисекундах.
433
