Eltex ME5200 [503/670] Show lldp interface
![Eltex ME5200 [503/670] Show lldp interface](/views2/1569351/page503/bg1f7.png)
0/ME5100:example_router01# show lldp
Wed Aug 2 17:27:50 2017
Ê Global LLDP information:
Ê LLDP status is ACTIVE
Ê LLDP advertisements are sent every 30 seconds
Ê LLDP hold time advertised is 61 seconds
Ê LLDP interface reinitialization delay is 2 seconds
Ê LLDP notifications interval is 10 seconds
Ê Fast Transmission sends 4 messages every 5 seconds
Ê LLDP agent codes:
Ê (N) Nearest Bridge, (NnT) Nearest non-TPMR Bridge
Ê (NC) Nearest Customer Bridge
Ê LLDP optional TLV codes:
Ê (MM) Enable management address TLV, (PD) Enable port description TLV
Ê (SC) Enable system capabilities TLV, (SD) Enable system description TLV
Ê (SM) Enable system name TLV
Ê port state tx state rx optional tlvs notifications notifications agent
Ê tables device
Ê -------- --------- --------- --------------- -------------- --------------- -----
Ê te 0/0/1 enabled enabled MM PD SC SD SM enabled enabled N
Ê te 0/0/2 enabled enabled MM PD SC SD SM enabled enabled N
Ê te 0/0/3 enabled enabled MM PD SC SD SM enabled enabled N
21.19. show lldp interface
Данная команда показывает настройки LLDP на заданном интерфейсе.
Синтаксис
show lldp interface INTERFACE
Параметры
• INTERFACE — интерфейс, в формате <ТИП ИНТЕРФЕЙСА> <UNIT>/<SLOT>/<PORT>,
Пример
482
