Eltex ME5200 [521/670] Match mode
![Eltex ME5200 [521/670] Match mode](/views2/1569351/page521/bg209.png)
Синтаксис
[no] match tc TRAFFIC_CLASS
Параметры
• TRAFFIC_CLASS — значение внутреннего класса трафика. Диапазон допустимых
значений: 0..7.
Необходимый уровень привилегий
p10
Командный режим
config-qos-class-map
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# class-map CLASS-MAP-01
0/ME5100:example_router01(config-class-map)# match tc 7
0/ME5100:example_router01(config-class-map)# no match tc 7
0/ME5100:example_router01(config-class-map)#
23.11. match-mode
Команда задает режим проверки условий (match) внутри классификатора в случае, если
задано несколько условий.
Отрицательная форма команды возвращает значение по умолчанию (any).
Синтаксис
match-mode { all | any }
no match-mode
Параметры
• all — должны быть соблюдены все условия;
• any — может быть соблюдено любое из условий (режим по умолчанию).
Необходимый уровень привилегий
p10
Командный режим
config-qos-class-map
Пример
500
