![Eltex ME5200 [424/670] Profile](/views2/1569351/page424/bg1a8.png)
0/ME5100:example_router01(config)# l2vpn xconnect-group test
0/ME5100:example_router01(config-xconnect-group)# p2p test
0/ME5100:example_router01(config-p2p)#
15.27. profile
Команда позволяет задать профиль параметров для шторм-контроля трафика в бридж-
домене
Отрицательная форма команды удаляет настройку
Синтаксис
profile NAME
no profile
Параметры
• NAME — строковое имя профиля (1..63)
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-interface-storm-control
config-l2vpn-bridge-domain-storm-control
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain Test
0/ME5100:example_router01(config-bridge-domain)# storm-control
0/ME5100:example_router01(config-storm-control)# profile SC-Profile
0/ME5100:example_router01(config-storm-control)#
15.28. pw
Данная команда создает pseudowire с заданными адресом удаленного маршрутизатора (PE)
и идентификатором псевдопровода (PW ID), и переходит в режим его конфигурирования.
Отрицательная форма команды удаляет данный pseudowire.
Синтаксис
[no] pw PEER_ADDRESS PW_ID
Параметры
• PEER_ADDRESS — IPv4 или IPv6 адрес соседа для данного pseudowire;
• PW_ID — число, которое будет использоваться в качестве pseudowire ID (1..1073741823).
403
