дополнительных параметров
Отрицательная форма команды отключает шторм-контроль
Синтаксис
[no] storm-control
Параметры
• Configure storm-control parameters
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
config-l2vpn-bridge-domain-interface
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain Test
0/ME5100:example_router01(config-bridge-domain)# storm-control
15.40. transport-mode
В режиме конфигурации бридж-домена (config-l2vpn-bridge-domain) и кросс-коннекта
(config-l2vpn-xconnect-group-p2p) данная команда позволяет установить в конфигурации тип
инкапсуляции Attachment circuit, которая будет использоваться в данных VPLS и VPWS
сервисах соответственно.
Отрицательная форма команды возвращает значение по умолчанию (ethernet).
Синтаксис
transport-mode { ethernet | vlan }
no transport-mode
Параметры
• ethernet — инкапсуляция, которая соответствует ethernet-кадрам (IEEE 802.3);
• vlan — инкапсуляция, которая соответствует тэгированным ethernet-кадрам (IEEE
802.1q).
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
config-l2vpn-xconnect-group-p2p
415
