13.72. route-map
Команда включает обработку принимаемых от соседа, отправляемых ему маршрутов в
указанном Address Family в соответствии с заданным route-map. Данная обработка
производится после применения prefix-list.
Отрицательная форма команды выключает указанную обработку.
Синтаксис
route-map { in | out } STRING
no route-map { in | out }
Параметры
• in — обработка принятых маршрутов;
• out — обработка анонсируемых маршрутов;
• STRING — имя route-map. Допустимая длина: 1..32.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor-address-family-ipv4-unicast
config-router-bgp-neighbor-address-family-ipv6-unicast
config-router-bgp-neighbor-address-family-l2vpn-vpls
config-router-bgp-neighbor-address-family-vpnv4-unicast
config-router-bgp-neighbor-address-family-vpnv6-unicast
config-router-bgp-peer-group-address-family-ipv4-unicast
config-router-bgp-peer-group-address-family-ipv6-unicast
config-router-bgp-peer-group-address-family-l2vpn-vpls
config-router-bgp-peer-group-address-family-vpnv4-unicast
config-router-bgp-peer-group-address-family-vpnv6-unicast
config-router-bgp-vrf-neighbor-address-family-ipv4-unicast
config-router-bgp-vrf-neighbor-address-family-ipv6-unicast
config-router-bgp-vrf-peer-group-address-family-ipv4-unicast
config-router-bgp-vrf-peer-group-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# address family ipv4 unicast
0/ME5100:example_router01(config-unicast)# route-map in ROUTE_MAP_IN
0/ME5100:example_router01(config-unicast)# route-map out ROUTE_MAP_OUT
0/ME5100:example_router01(config-unicast)# no route-map out
306
