11.40. metric-value
Данная команда позволяет установить базовое значение метрики для правила
редистрибуции.
Отрицательная форма команды возвращает значение по умолчанию (0).
Синтаксис
metric-value METRIC
no metric-value
Параметры
• METRIC — значение метрики (0..16777215)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution
config-router-ospfv2-vrf-redistribution
config-router-ospfv3-redistribution
config-router-ospfv3-vrf-redistribution
Пример:
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution static STATIC
0/ME5100:example_router01(config-static)# metric-value 10
0/ME5100:example_router01(config-static)#
11.41. mtu-ignore
Данная команда отключает проверку значения MTU в OSPF Database Description пакетах при
установлении соседства на текущем интерфейсе.
Отрицательная форма команды включает проверку значения MTU в OSPF DB Description
пакетах, если значение больше MTU интерфейса, соседство не устанавливается.
Синтаксис
[no] mtu-ignore
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
157
