Eltex ME5200 [504/670] Show lldp neighbors
![Eltex ME5200 [504/670] Show lldp neighbors](/views2/1569351/page504/bg1f8.png)
0/ME5100:example_router01# show lldp interface tengigabitethernet 0/0/1
Fri Aug 4 15:51:20 2017
Ê Interface Tengigabitethernet 0/0/1
Ê Agent type: nearest-bridge
Ê Tx: enabled
Ê Rx: enabled
Ê Optional TLVS:
Ê Enable management address TLV is transmited
Ê Enable port description TLV is transmited
Ê Enable system capabilities TLV is transmited
Ê Enable system description TLV is transmited
Ê Enable system name TLV is transmited
Ê Notification tables is enabled
Ê Notification device is enabled
21.20. show lldp neighbors
Данная команда показывает информацию об LLDP-нейборах в табличном виде.
Использование ключа "detail" без параметров позволяет просмотреть полную информацию
об LLDP-нейборах для всех интерфейсов.
Синтаксис
show lldp neighbors [ detail | INTERFACE ]
Параметры
• INTERFACE — интерфейс, в формате <ТИП ИНТЕРФЕЙСА> <UNIT>/<SLOT>/<PORT>,
Пример
0/ME5100:example_router01#show lldp neighbors
Fri Aug 4 15:18:24 2017
Ê Capability codes:
Ê (R) Router, (B) Bridge, (T) Telephone, (C) DOCSIS Cable Device
Ê (W) WLAN Access Point, (r) Repeater, (H) Host, (s) Station only
Ê (TP) - Two Ports MAC Relay, (S) - S-VLAN, (C) - C-VLAN, (O) Other
Ê LLDP agent codes:
Ê (N) Nearest Bridge, (NnT) Nearest non-TPMR Bridge
Ê (NC) Nearest Customer Bridge
Ê local port device id port id capabilities agent system name
Ê ------------ ------------------ ------------- ------------- ------ ------------
Ê te 0/0/1 A8:F9:4B:A6:4E:40 te1/0/1 B R N MNG_ME 17.31
Ê te 0/0/3 A8:F9:4B:8B:95:00 te 0/1/3 B R N DR30-17-150
::
483
