Параметры
• TC_MAP_INDEX — индекс Traffic Class Map. Числовое значение в диапазоне:
1..4294967295
Необходимый уровень привилегий
p10
Командный режим
config-qos
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# exit
0/ME5100:example_router01(config)# no tc-map 1
23.35. tc-map input
Команда назначает интерфейсу внутренний классификатор для классификации входящего
трафика.
Отрицательная форма команды удаляет классификатор с интерфейса.
Синтаксис
tc-map input TC_MAP_INDEX
no tc-map input
Параметры
• TC_MAP_INDEX — индекс Traffic Class Map. Числовое значение в диапазоне:
1..4294967295
Необходимый уровень привилегий
p10
Командный режим
config-qos-interface
Пример
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# tc-map input 1
0/ME5100:example_router01(config-tengigabitethernet)# no tc-map input
0/ME5100:example_router01(config-tengigabitethernet)#
515
