Eltex ME5200 [487/670] Holdtime
![Eltex ME5200 [487/670] Holdtime](/views2/1569351/page487/bg1e7.png)
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# sa-filter in 1
0/ME5200:example_router01(config-in)# group-address 239.0.0.0/0.0.0.255
0/ME5200:example_router01(config-in)#
20.6. holdtime
Команда задает время жизни MSDP сессии в секундах.
Отрицательная форма команды возвращает значение по умолчанию (75 секунд).
Синтаксис
holdtime SECONDS
no holdtime
Параметры
• SECONDS — время в секундах (3..150)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp
config-router-msdp-vrf
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# holdtime 9
0/ME5200:example_router01(config-msdp)#
20.7. keepalive
Команда задает время в секундах между периодическими отправками Keepalive-пакетов.
Отрицательная форма команды возвращает значение по умолчанию (60 секунд).
Синтаксис
keepalive SECONDS
no keepalive
Параметры
• SECONDS — время в секундах (1..60)
466
