GLOBAL
Пример
0/FMC0:example_router01# show mpls ldp forwarding
Thu Aug 17 05:16:05 2017
Ê Codes:
Ê R = Remote LFA FRR backup
Ê Prefix Label(s) out Outgoing Interface Next Hop flags
Ê --------------------- ------------- ------------------- --------------------- ------
Ê 3.3.3.3/32 16 te 0/1/6 100.100.24.0
Ê 4.4.4.4/32 ImpNull te 0/1/6 100.100.24.0
Ê 5.5.5.5/32 17 te 0/1/6 100.100.24.0
Ê 6.6.6.6/32 18 te 0/1/6 100.100.24.0
0/FMC0:example_router01#
14.24. show mpls ldp igp sync
Команда выводит информацию о состоянии синхронизации протокола LDP с IGP
протоколами на интерфейсах. Указание параметров позволяет фильтровать вывод по
заданному IGP протоколу.
Синтаксис
show mpls ldp igp sync [ isis | ospfv2 ]
Параметры
• isis — LDP IGP Sync для IS-IS;
• opsfv2 — LDP IGP Sync для OSPFv2.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
381
