5.21. port
При использовании в разделе настройки TACACS+-сервера (config-aaa-tacacs-server-host-ipv4
и config-aaa-tacacs-server-vrf-host-ipv4) данная команда задает номер порта, по которому
маршрутизатор будет обращаться к удаленному TACACS+-серверу.
При использовании в разделах настройки SSH- и Telnet-серверов (config-ssh-server-vrf и
config-telnet-server-vrf) команда задает номер порта, по которому будет принимать
входящие соединения соответствующий локальный сервер.
Отрицательная форма команды устанавливает значение по умолчанию.
Синтаксис
port PORT
no port
Параметры
• PORT — номер порта, принимает значения от 1 до 65535.
Командный режим
config-aaa-tacacs-server-host-ipv4
config-aaa-tacacs-server-vrf-host-ipv4
config-ssh-server-vrf
config-telnet-server-vrf
Пример
0/ME5100:example_router01(config)# tacacs-server host ipv4 192.168.16.245
0/ME5100:example_router01(config-ipv4)# port 993
0/ME5100:example_router01(config)# telnet server vrf default
0/ME5100:example_router01(config-vrf)# port 20023
5.22. priority
Данная команда назначает приоритет (очередность) использования указанному TACACS+
или RADIUS-серверу.
Отрицательная форма команды устанавливает значение по умолчанию.
Синтаксис
priority PRIO
no priority
Параметры
• PRIO — приоритет заданного AAA-сервера в общем списке серверов.
62
