Eltex ME5200 [426/670] Route target
![Eltex ME5200 [426/670] Route target](/views2/1569351/page426/bg1aa.png)
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# pw 172.16.0.2 100
0/ME5100:example_router01(config-pw)# pw-class test
0/ME5100:example_router01(config-pw)#
15.30. rd
В режиме конфигурации параметров BGP Auto-discovery бридж-домена или кросс-коннекта
данная команда задает Route Distinguisher (RD).
Отрицательная форма команды удаляет данный элемент из конфигурации.
Синтаксис
rd RD_FORMAT
no rd
Параметры
• RD_FORMAT — значение RD в формате AS:nn, либо IPv4:nn, где:
◦ AS - значение в формате Autonomous System;
◦ IPv4 - значение в формате IPv4-адреса;
◦ nn - число.
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-autodiscovery-bgp
config-l2vpn-xconnect-group-p2p-autodiscovery-bgp
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# autodiscovery bgp
0/ME5100:example_router01(config-bgp)# rd 10.0.0.3:200
0/ME5100:example_router01(config-bgp)#
15.31. route-target
В режиме конфигурации параметров BGP Auto-discovery бридж-домена или кросс-коннекта
данная команда задает Route Target (RT) и переходит в режим конфигурации
дополнительных настроек.
Отрицательная форма команды удаляет данные настройки из конфигурации.
Синтаксис
405
