Eltex ME5200 [196/670] Show ospfv2 area link state
![Eltex ME5200 [196/670] Show ospfv2 area link state](/views2/1569351/page196/bgc4.png)
Ê Number errors:
Ê instance id: 0, bad IP header length: 0
Ê header length: 0, bad IP header length: 0
Ê no virtual link: 0, version: 0
Ê bad source: 0, resource errors: 0
Ê Number of packets received have been dropped: 0
Ê Area 0.0.0.0, up
Ê Area can carry data traffic: false
Ê SPF algorithm executed 19 times
Ê Number of number of area border routers: 1, Autonomous routers: 1
Ê Number of Translator State changes: 0
Ê NSSA Border router state: disabled
Ê Number of LSA (LS type-1) count: 1, checksum: 0x00008689
Ê Number of LSA with LS type-2 count: 0
Ê Number of LSA with LS type-3 count: 1, checksum: 0x0000A109
Ê Number of LSA with LS type-4 count: 0, checksum: 0x00000000
Ê Number of LSA with LS type-7 (NSSA) count: 0, checksum: 0x00000000
Ê Number of LSA with LS type-10 (opaque) count: 0, checksum: 0x00000000
Ê Number of with LS type-7 (NSSA): 0, checksum: 0x00000000
Ê Total number of LSA: 2, checksum: 0x00012792
Ê Number of interfaces in this area is: 5
Ê Area 0.0.0.1, up
Ê Area can carry data traffic: false
Ê SPF algorithm executed 19 times
Ê Number of number of area border routers: 1, Autonomous routers: 0
Ê Number of Translator State changes: 0
Ê NSSA Border router state: disabled
Ê Number of LSA (LS type-1) count: 2, checksum: 0x000110DB
Ê Number of LSA with LS type-2 count: 0
Ê Number of LSA with LS type-3 count: 1, checksum: 0x000093E2
Ê Number of LSA with LS type-4 count: 0, checksum: 0x00000000
Ê Number of LSA with LS type-7 (NSSA) count: 0, checksum: 0x00000000
Ê Number of LSA with LS type-10 (opaque) count: 0, checksum: 0x00000000
Ê Number of with LS type-7 (NSSA): 0, checksum: 0x00000000
Ê Total number of LSA: 3, checksum: 0x0001A4BD
Ê Number of interfaces in this area is: 2
11.66. show ospfv2 area link-state
Данная команда выводит информацию о всех LSA, которые порождены в OSPFv2 area.
Синтаксис
show ospfv2 [vrf { all | VRF_NAME }] area link-state
Параметры
175
Содержание
