Eltex ME5200 [552/670] Show lacp redundancy groups
![Eltex ME5200 [552/670] Show lacp redundancy groups](/views2/1569351/page552/bg228.png)
0/ME5100:example_router01# show lacp port tengigabitethernet 0/0/1
Tue Oct 10 09:57:57 2017
Ê Port: te 0/0/1
Ê ----------------------------
Ê Port state up
Ê Port channel bundle 1
Ê BFD Information:
Ê Source IP none
Ê Destination IP
Ê Local information:
Ê Port State Port ID System ID
Ê ------------------- -------------------------- -------------
--------------------------
Ê te 0/0/1 collecting-distributing 32768.41 32768.A8:F9:4B:8B:A1:80
Ê Flags:
Ê A - Port is in active mode. P - Port is in passive mode.
Ê S - Port sends PDUs at slow rate. F - Port sends PDUs at fast rate.
Ê U - Port is aggregated. Y - Port is synchronized
Ê C - Port is collecting. D - Port is distributing
Ê T - Port is using default values for partner information
Ê E - Information about partner has expired
Ê Partner's information:
Ê Port TX state Port ID System ID
Ê ------------------- --------- ------------- --------------------------
Ê te 0/0/1 PSUYCD 1.51 1.A8:F9:DE:AD:44:02
Ê Age of the port in the current state: 287739
Ê micro-BFD information:
Ê BFD service is not running
24.22. show lacp redundancy-groups
Вывод информации о группе избыточности.
Синтаксис
show lacp redundancy-groups GROUP_ID
Параметры
• GROUP_ID — номер MCLAG-группы.
Необходимый уровень привилегий
p2
531
