0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa exclude
0/ME5100:example_router01(config-tengigabitethernet)#
11.28. lfa filter
Данная команда создает в конфигурации именованное правило для фильтрации в таблице
маршрутизации OSPF IP LFA FRR запасных маршрутов и переводит в режим
конфигурирования этого правила.
Отрицательная форма команды удаляет данное правило.
Синтаксис
[no] lfa filter STRING
Параметры
• STRING — имя правила (1..128).
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# lfa filter FILTER
0/ME5100:example_router01(config-filter)#
11.29. lfa include-all
Данная команда включает возможность построения альтернативных маршрутов для всех
интерфейсов, участвующих в OSPF-процессе маршрутизации.
Отрицательная форма команды выключает возможность построения альтернативных
шлюзов для всех интерфейсов, участвующих в OSPF-процессе маршрутизации.
Синтаксис
[no] lfa include-all
148
