Eltex ME5200 [171/670] Lfa remote
![Eltex ME5200 [171/670] Lfa remote](/views2/1569351/page171/bgab.png)
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa protection disable
0/ME5100:example_router01(config-tengigabitethernet)#
11.31. lfa remote
Данная команда включает поддержку OSPFv2 IP Remote Loop-Free Alternate Fast Reroute
(RLFA FRR). Подробнее в RFC 7490
Отрицательная форма команды отключает поддержку OSPFv2 IP Remote Loop-Free Alternate
Fast Reroute.
Синтаксис
[no] lfa remote
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# lfa remote
0/ME5100:example_router01(config-filter)#
11.32. match nexthop
Данная команда создает в конфигурации устройства ограничение на использование
определенных IPv4-префиксов в определенном правиле редистрибуции. Разрешается
использовать префиксы, у которых IPv4 адрес шлюза входит в указанный префикс.
Отрицательная форма команды разрешает использовать в данном правиле редистрибуции
все префиксы, которые есть в указанном протоколе.
Синтаксис
match nexthop IPv4_PREFIX_FORMAT
[no] match nexthop
Параметры
• IPv4_PREFIX_FORMAT - значение префикса в формате IPv4-подсети.
Необходимый уровень привилегий
p10
150
