13.102.21. set comm-list add
Команда задает именованный список BGP community, который будет добавлен маршрутам,
удовлетворяющим условиям указанного правила route-map.
Отрицательная форма команды удаляет настройку.
Синтаксис
set comm-list add COMMLIST
no set comm-list add
Параметры
• COMMLIST — имя списка комьюнити (1..32)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)# set comm-list add CommList
0/ME5100:example_router01(config-seq-num)#
13.102.22. set comm-list delete
Команда задает именованный список BGP community, который будет удален из маршрутов,
удовлетворяющих условиям указанного правила route-map.
Отрицательная форма команды удаляет настройку.
Синтаксис
set comm-list delete COMMLIST
no set comm-list delete
Параметры
• COMMLIST — имя списка комьюнити (1..32)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
348
