Отрицательная форма команды разрешает добавление отфильтрованных OSPFv2 IP LFA FRR
маршрутов.
Синтаксис
[no] disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-lfa-filter
config-router-ospfv2-vrf-lfa-filter
config-router-ospfv3-lfa-filter
config-router-ospfv3-vrf-lfa-filter
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# lfa filter FILTER
0/ME5100:example_router01(config-filter)# disable
0/ME5100:example_router01(config-filter)#
11.13. effect
Данная команда позволяет создать в конфигурации условие анонсирования суммарного
префикса, указанного в area-aggregate.
Отрицательная форма команды возвращает значение по умолчанию (advertise-matching).
Синтаксис
effect { advertise-matching | do-not-advertise-matching }
no effect
Параметры
• advertise-matching — параметр, при выборе которого префикс анонсируется, если
есть префикс входящий в префикс area-aggregate;
• do-not-advertise-matching — параметр, при выборе которого префикс не
анонсируется, если есть префикс входящий в префикс area-aggregate.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-area-aggregate
137
