![Eltex ME5200 [448/670] Spanning tree mstp msti](/views2/1569351/page448/bg1c0.png)
Пример
0/ME5100:example_router01(config)# spanning-tree mstp maximum-hops 20
0/ME5100:example_router01(config)#
16.16. spanning-tree mstp msti
Команда создает экземпляр протокола MSTP (MST Instance) и входит в режим
конфигурирования дополнительных настроек данного экземпляра.
Отрицательная форма команды удаляет экземпляр MSTP.
Синтаксис
spanning-tree mstp msti MSTI_ID
no spanning-tree mstp msti
Параметры
• MSTI_ID — численное значение идентификатора MSTI (1..4094)
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# spanning-tree mstp msti 1
0/ME5100:example_router01(config-msti)#
16.17. spanning-tree provider-bridge
Команда переключает режим работы STP на устройстве в Spanning Tree Protocol (for provider
bridges) IEEE 802.1ad. При этом в BPDU используется MAC адрес назначения 01-80-C2-00-00-08.
Отрицательная форма команды возвращает режим по умолчанию - Spanning Tree Protocol
(for bridges) IEEE 802.1d. В этом режиме в BPDU используется MAC адрес назначения 01-80-C2-
00-00-00
Синтаксис
[no] spanning-tree { stp | mstp | rstp } provider-bridge
Параметры
• stp — Spanning Tree Protocol
• mstp — Multiple Spanning Tree Protocol
• rstp — Rapid Spanning Tree Protocol
427
