Отрицательная форма команды устанавливает значение по умолчанию (системный MAC-
адрес).
Синтаксис
system-mac-addr MAC
no system-mac-addr
Параметры
• MAC — системный MAC-адрес в формате XX:XX:XX:XX:XX:XX.
Необходимый уровень привилегий
p10
Командный режим
config-lacp-redundancy-groups-redundancy-group
Пример
0/ME5100:example_router01(config)# lacp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# port-priority 100
0/ME5100:example_router01(config-tengigabitethernet)#
24.25. system-priority
Приоритет устройства в группе избыточности.
Отрицательная форма команды устанавливает значение по умолчанию (32768).
Синтаксис
system-priority (1-65535)
no system-priority
Параметры
• (1-65535) — Задание приоритета
Необходимый уровень привилегий
p10
Командный режим
config-lacp-redundancy-groups-redundancy-group
Пример
0/ME5100:example_router01(config)# lacp redundancy-groups redundancy-group 10
0/ME5100:example_router01(config-redundancy-group)# system-priority 100
0/ME5100:example_router01(config-redundancy-group)#
533
