Eltex ME5200 [345/670] Show bgp prefix
![Eltex ME5200 [345/670] Show bgp prefix](/views2/1569351/page345/bg159.png)
0/ME5100:example_router01# show bgp ipv4 unicast neighbors 4.4.4.4 routes
Tue Feb 6 19:42:33 2018
Ê BGP router identifier 1.1.1.1, local AS number 100
Ê BGP graceful restart time: 120 secs
Ê BGP table state: active
Ê BGP scan interval: 120 secs
Ê Status codes: d damped, h history, > best, S stale, * active, u untracked, i
internal
Ê Origin codes: i igp, e egp, ? incomplete
Ê Received bgp routes from neighbor: 4.4.4.4
Ê Network Next hop Metric LocPrf Weight Path
Ê ------------------------ ---------------- ------- ------- ------- -----
Ê *>i 20.20.0.0/32 2.2.2.2 220 120 0 i
Ê *>i 22.11.0.0/24 2.2.2.2 110 110 0 ?
Ê *>i 22.21.21.0/24 2.2.2.2 0 100 0 i
Ê *>i 22.22.0.0/24 2.2.2.2 220 120 0 i
Ê *>i 50.50.0.0/24 5.5.5.5 0 100 0 i
Ê *>i 172.16.56.0/24 5.5.5.5 0 100 0 i
Ê *>i 172.16.56.0/25 5.5.5.5 0 100 0 i
Ê *>i 172.16.56.128/25 5.5.5.5 0 100 0 i
Ê *>i 172.17.44.0/24 4.4.4.4 0 100 0 i
Ê *>i 172.17.44.0/25 4.4.4.4 0 100 0 i
Ê *>i 172.17.44.128/25 4.4.4.4 0 100 0 i
Ê Total paths: 11
0/ME5100:example_router01#
13.88. show bgp prefix
Команда выводит информацию о маршрутах до заданного префикса для указанного vrf. Без
указания параметра vrf команда выводит информацию из глобальной таблицы (vrf default).
Синтаксис
show bgp [ vrf { all | VRF_NAME } ] [ ipv4 unicast ] prefix IPv4_PREFIX_FORMAT
Параметры
• ipv4 — IPv4 AFI;
• unicast — Unicast SAFI;
• IPv4_PREFIX_FORMAT — значение префикса в формате IPv4-подсети;
• VRF_NAME — имя VRF.
Необходимый уровень привилегий
p2
324
