![Eltex ME5200 [229/670] Me5100 example_router01 config router isis process_name 0 me5100 example_router01 config isis interface tengigabitethernet 0 0 1 0 me5100 example_router01 config tengigabitethernet ldp igp synchronization 0 me5100 example_router01 config tengigabitethernet](/img/pdf.png)
Eltex ME5200 [229/670] Me5100 example_router01 config router isis process_name 0 me5100 example_router01 config isis interface tengigabitethernet 0 0 1 0 me5100 example_router01 config tengigabitethernet ldp igp synchronization 0 me5100 example_router01 config tengigabitethernet
![Eltex ME5200 [229/670] Me5100 example_router01 config router isis process_name 0 me5100 example_router01 config isis interface tengigabitethernet 0 0 1 0 me5100 example_router01 config tengigabitethernet ldp igp synchronization 0 me5100 example_router01 config tengigabitethernet](/views2/1569351/page229/bge5.png)
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# ldp-igp-synchronization
0/ME5100:example_router01(config-tengigabitethernet)#
12.28. level
В режиме конфигурации процесса маршрутизации IS-IS (config-router-isis и config-router-isis-
vrf) данная команда позволяет войти в режим конфигурации определенного IS-IS уровня
для данного процесса маршрутизации.
В режиме конфигурации интерфейса, который участвует в IS-IS процессе маршрутизации
(config-router-isis-interface и config-router-isis-vrf-interface) данная команда позволяет войти в
режим конфигурации определенного IS-IS уровня для данного интерфейса.
В режиме конфигурации процесса маршрутизации IS-IS (config-router-isis и config-router-isis-
vrf) отрицательная форма команды удаляет всю конфигурацию данного уровня в данном
процессе маршрутизации.
В режиме конфигурации интерфейса, который участвует в IS-IS процессе маршрутизации
(config-router-isis-interface и config-router-isis-vrf-interface) отрицательная форма команды
удаляет всю конфигурацию данного уровня на данном интерфейсе.
Синтаксис
[no] level { level-1 | level-2 }
Параметры
• level-1 — вход в режим конфигурирования 1 уровня протокола IS-IS;
• level-2 — вход в режим конфигурирования 2 уровня протокола IS-IS.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-interface
config-router-isis-vrf
config-router-isis-vrf-interface
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# level level-2
0/ME5100:example_router01(config-level)#
208
