2.20. show system resources capacity
Данной командой осуществляется просмотр информации о текущем использовании памяти
устройства.
Синтаксис
show system resources capacity
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show system resources capacity
Thu Feb 7 15:06:27 2019
Ê Memory resources for ME5100:
Ê RAM: 1771 MB / 7852 MB (22.55% used)
Ê ROOTFS: 1489 MB / 3696 MB (40.29% used)
Ê TMPFS: 274 MB / 1024 MB (26.76% used)
0/ME5100:example_router01#
2.21. show system resources cpu
Данной командой осуществляется просмотр информации о текущем использовании
процессора устройства.
Синтаксис
show system resources cpu
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
22
