![Eltex ME5200 [146/670] Destination](/views2/1569351/page146/bg92.png)
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# destination 40.10.0.0/16 40.10.0.1
0/ME5100:example_router01(config-destination)# interface tengigabitethernet 0/0/7
0/ME5100:example_router01(config-tengigabitethernet)# bfd fast-detect
0/ME5100:example_router01(config-tengigabitethernet)#
10.4. destination
Создание статического маршрута в конфигурации семейства AFI/SAFI.
Отрицательная форма команды удаляет заданный статический маршрут.
Синтаксис
[no] destination { IPv4_pref | IPv6_pref } { IPv4_nhop | IPv6_nhop }
Параметры
• IPv4_pref (X.X.X.X/N) — IPv4 префикс маршрута;
• IPv6_pref (X:X:X:X::X/N) — IPv6 префикс маршрута;
• IPv4_nhop (X.X.X.X) — IPv4 адрес следующего узла (nexthop) для маршрута;
• IPv6_nhop (X:X:X:X::X) — IPv6 адрес следующего узла (nexthop) для маршрута.
Необходимый уровень привилегий
p10
Командный режим
config-router-static-ipv4-unicast
config-router-static-ipv6-unicast
config-router-static-ipv4-multicast
config-router-static-ipv6-multicast
Пример
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# destination 40.10.0.0/16 40.10.0.1
0/ME5100:example_router01(config-destination)#
10.5. interface
Команда принудительно задает интерфейс, через который будет направлен трафик по
данному статическому маршруту, и производит переход в режим настройки
дополнительных параметров статического маршрута.
Отрицательная форма команды удаляет данный интерфейс из текущего маршрута.
125
