Eltex ME5200 [361/670] Match address family
![Eltex ME5200 [361/670] Match address family](/views2/1569351/page361/bg169.png)
Командный режим
config-prefix-list-seq-num
Пример
0/ME5100:example_router01(config)# prefix-list Test
0/ME5100:example_router01(config-prefix-list)# seq-num 10
0/ME5100:example_router01(config-seq-num)# le 24
0/ME5100:example_router01(config-seq-num)#
13.102.7. match address-family
Команда создает условие принадлежности префикса заданному AFI/SAFI.
Отрицательная форма команды удаляет условие.
Синтаксис
match address-family { ipv4 | ipv6 | vpnv4 | vpnv6 }
no match address-family
Параметры
• ipv4 — IPv4 unicast
• ipv6 — IPv6 unicast
• vpnv4 — IPv4 VPN
• vpnv6 — IPv6 VPN
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq 10
0/ME5100:example_router01(config-seq-num)# match address-family ipv4
0/ME5100:example_router01(config-seq-num)#
13.102.8. match as-path
Команда задает регулярное выражение для BGP AS Path.
Отрицательная форма команды удаляет условие.
Синтаксис
match as-path REGEXP
340
