19. НАСТРОЙКА MULTICAST: IGMP
19.1. groups-limit
Команда задает максимальное количество широковещательных(multicast) групп, на
которые может быть подписан заданный интерфейс. При задании значения "0"
ограничение на количество групп снимается.
Отрицательная форма команды снимает ограничение, значение по умолчанию (0).
Синтаксис
groups-limit INTEGER
no groups-limit
Параметры
• INTEGER — количество групп. Диапазон допустимых значений: 0..4294967295
Необходимый уровень привилегий
p10
Командный режим
config-router-igmp-interface
Пример
0/ME5100:example_router01# configure
0/ME5100:example_router01(config)# router igmp interface tengigabitethernet 0/0/4
0/ME5100:example_router01(config-tengigabitethernet)# groups-limit 10
0/ME5100:example_router01(config-tengigabitethernet)#
19.2. immediate-leave
Команда включает немедленную отписку интерфейса от широковещательной группы при
получении сообщения IGMP leave на заданном интерфейсе.
Отрицательная форма команды возвращает поведение по умолчанию, после получения
сообщения IGMP Leave в интерфейс отправляется IGMP Group Query в целях проверки
оставшихся подписчиков.
Синтаксис
[no] immediate-leave
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
452
