Thu Jul 20 17:08:22 2017
Ê Routing Process: test, with ID 33.33.33.33
Ê OSPF Link State Database (Area 0.0.0.0)
Ê Link ID ADV Router Age Seq# Checksum Type
Ê ----------------- -------------- ---------- ----------- ----------- -----
Ê 33.33.33.33 33.33.33.33 00:25:34 0x80000002 0x0000848A router-lsa
Ê 10.10.14.0 33.33.33.33 00:16:15 0x80000001 0x0000FDB7 summary-lsa
Ê 11.11.11.11 33.33.33.33 00:18:52 0x80000001 0x0000A109 summary-lsa
Ê 100.99.223.0 33.33.33.33 00:19:12 0x80000001 0x000033FC summary-lsa
Ê Link State Database, Link-Local for network Links (Interface Tengigabitethernet
0/0/1, Area 0.0.0.0)
Ê Link State Database, Link-Local for network Links (Interface Tengigabitethernet
0/0/9, Area 0.0.0.0)
Ê Link State Database, Link-Local for network Links (Interface Tengigabitethernet
0/0/1.30, Area 0.0.0.0)
Ê Link State Database, Link-Local for network Links (Interface Loopback 1, Area
0.0.0.0)
Ê Link State Database, Link-Local for network Links (Interface Loopback 2, Area
0.0.0.0)
Ê OSPF Link State Database (Area 0.0.0.1)
Ê Link ID ADV Router Age Seq# Checksum Type
Ê ----------------- -------------- ---------- ----------- ----------- -----
Ê 22.22.22.22 22.22.22.22 00:18:58 0x80000008 0x00003DD5 router-lsa
Ê 33.33.33.33 33.33.33.33 00:16:15 0x80000009 0x0000C30E router-lsa
Ê 0.0.0.0 33.33.33.33 00:25:34 0x80000002 0x000091E3 summary-lsa
Ê Link State Database, Link-Local for network Links (Interface Tengigabitethernet
0/0/2, Area 0.0.0.1)
Ê Link State Database, Link-Local for network Links (Interface Tengigabitethernet
0/0/1.101, Area 0.0.0.1)
Ê External Link States:
Ê Link ID ADV Router Age Seq# Checksum Type
LSA
177
