0/ME5100:example_router01# show interfaces counters
Tue Oct 3 05:33:53 2017
Ê Interface IF index Recv, Bytes Recv, Packets Input Errors
Sent, Bytes Sent, Packets Output Errors
Ê ---------------- --------- --------------------- ---------------------
--------------------- --------------------- ---------------------
---------------------
Ê te 0/0/1 25 0 0 0
270 3 0
Ê te 0/0/2 12 0 0 0
270 3 0
Ê te 0/0/3 26 0 0 0
270 3 0
Ê te 0/0/4 27 0 0 0
270 3 0
Ê te 0/0/5 28 0 0 0
0 0 0
Ê te 0/0/6 14 68527837 640129 0
2455839 19183 0
Ê te 0/0/7 29 0 0 0
0 0 0
Ê te 0/0/8 30 0 0 0
0 0 0
Ê te 0/0/9 3 6650693 50889 0
270 3 0
Ê te 0/0/10 9 6650693 50889 0
270 3 0
Ê te 0/0/11 31 6641649 50756 0
834 9 0
Ê te 0/0/12 2 93889837 761784 0
93745892 761835 0
Ê te 0/0/13 16 0 0 0
0 0 0
Ê te 0/0/14 32 0 0 0
0 0 0
Ê te 0/0/15 33 0 0 0
0 0 0
Ê te 0/0/16 34 0 0 0
0 0 0
Ê te 0/0/17 35 25324824704 98926073 0
178290 1633 0
Ê te 0/0/18 36 239040 3735 0
25707552724 98878017 0
Ê te 0/0/19 37 2220 20 0
25325002752 98927701 0
Ê te 0/0/20 38 73015558 667656 0
270 3 0
Ê bu 1 22 93888301 761772 0
93745460 761831 0
0/ME5100:example_router01#
108
