ESIE06-05 Procedure for Software Upload
Part 3 – Troubleshooting 3–37
33
4
5
1
4. Select files to be uploaded and push
“Add=>”
(Or in case all files can be uploaded push
“Add all =>”)
(Remark: if correct software is already
present, then it is possible only to select
a parameter file)
Result: A selection of files to be uploaded is made.
Action Result
