Fuel System (Fuel Injection)
4-6
25/30 2006
17-1
1
1-1
1-4
1-2
1-3
10
17
17-3
17-2
17-3
10-17
10-1
10-12
10-4
10-6
10-2
10-11
10-14
10-15
10-13
10-16
10-8
10-9
10-5
10-3
10-7
17-2
17-1
17-1
10-12-1
10-10
10-18
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
1 Fuel Filter 1
1-1 Cup 1
1-2 Filter 1
1-3 O Ring 1
1-4 O Ring A 1
10 Vapor Separator 1
10-1
O Ring 1
10-2
Screw 5 M4 L=16mm
10-3
Float 1
10-4
Float Arm Pin 1
10-5
Screw 1 M4 L=8mm
10-6
Float Valve 1 with Needle Valve
10-7
Clip 1
10-8
Drain Screw 1
10-9
Drain Screw O Ring 1
10-10
Terminal Holder 1
10-11
O Ring 1
10-12
Fuel Feed Pump 1
10-12-1
Filter 1
10-13
Fuel Regulator 1
10-14
O Ring 1
10-15
Grommet 1
10-16
Screw 2
10-17
Rubber Hose 1 for draining
Ref.
No.
Description Remarks
Q'ty
10-18
Grommet 1
17 Fuel Cooler 1
17-1
O Ring, 1.9-7.8 6
17-2
O Ring, 1.9-6.8 2
17-3
Screw 4 M4 L=10mm
Ref.
No.
Description Remarks
Q'ty
Fuel Pump, Fuel Rail, Vapor Separator
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
4st
OIL
4st OIL
P/L Fig. 5
