14
Slight run out of the working tool that can be sometimes observed after
starting the tool without load is normal. Working tool centres automatically at
touching processed material. In no way it aects precision of drilling.
OPERATION AND MAINTENANCE
Remove the battery from the device before commencing any
activities related to installation, adjustment, repair or maintenance.
MAINTENANCE AND STORAGE
• Cleaning the device after each use is recommended.
• Do not use water or any other liquid for cleaning.
• Clean the device with a dry cloth or blow through with compressed air at
low pressure.
• Do not use any cleaning agents or solvents, they may damage plastic parts.
• Clean ventilation holes in the motor casing regularly to prevent device
overheating.
• Always store the tool in a dry place, beyond reach of children.
• Store the device with the battery removed.
All defects should be repaired by service workshop authorized by the
manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless Rotary Hammer Drill 58G027
Parameter Value
Battery voltage 18 V DC
Rated rotational speed 0–1420 rpm
Impact rate 0–5000 min
-1
Impact energy 2.2J
Working tool shank SDS Plus
Drilling diameter – wood 28 mm
Drilling diameter – steel 13 mm
Drilling diameter – concrete 22 mm
Protection class III
Weight 2.1 kg
Year of production 2021
58G027 denes type and indication of the device
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C 4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2021 2021
Graphite Energy+ System Charger
Parameter Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2021
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure level: Lp
A = 86,4 dB (A) K=3dB (A)
Sound power level: LwA =97,4 dB (A) K=3dB (A)
Vibration acceleration value (additional handle): ah = 6,052 m/s
2
K= 1,5 m/s
2
Vibration acceleration value (main handle): ah = 5,783 m/s
2
K= 1,5 m/s
2
Noise produced by the device is dened with: level of produced sound
pressure Lp
A
and level of sound power Lw
A
(where K is measurement
uncertainty). Vibrations produced by the device are dened with vibration
acceleration value a
h
(where K is measurement uncertainty).
Sound pressure Lp
A
, sound power Lw
A
and vibration acceleration ah specied
in this manual have been measured in accordance with EN 60745-1. Specied
vibration level a
h
can be used to compare tools and for initial evaluation of
exposition to vibrations.
Specied vibration level is representative for main applications of the device.
When the device is used for other purposes or with dierent working tools,
the vibration level may change. Insucient or too rare maintenance may
increase vibration level. The abovementioned factors may lead to higher
exposure to vibrations during whole working time.
To precisely dene exposure to vibrations, include periods when the device
is switched o and when it is switched on but not used for working. Once all
factors have been carefully considered, total exposition to vibrations may be
signicantly lower.
To protect the user from results of exposure to vibrations, use additional
safety measures such as: device and working tool periodic maintenance,
proper hand temperature conditions, good work organisation.
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed o with
household waste and, instead, should be utilized at
appropriate facilities. Information on utilization can be
provided by the product vendor or the local authorities.
Waste electrical and electronic equipment contains
substances that are not neutral to the natural environment.
Equipment that is not recycled constitutes a potential hazard
to the environment and to human health.
Li-Ion
Do not dispose the batteries with household wastes, do
not throw in re or water. Damaged or worn out batteries
should be properly recycled in accordance with applicable
directive for battery disposal.. Batteries should be returned
to collection points fully discharged, if the batteries are not
completely discharged, they must be protected against short
circuits. Used batteries can be returned free of charge at
commercial locations. The buyer of the goods is obliged to
return the used batteries.
* Right to introduce changes is reserved.
“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa with seat
in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to
this instruction (hereinafter Instruction), including, but not limited to, text, photographies,
schemes, drawings and layout of the instruction, belong to Grupa Topex exclusively and
are protected by laws accordingly to Copyright and Related Rights Act of 4 February 2004
(ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006 No 90 item 631 with later
ammendments). Copying, processing, publishing, modications for commercial purposes
of the entire Instruction or its parts without written permission of Grupa Topex are strictly
forbidden and may cause civil and legal liability.
