Chapter 27 IEEE 802.1x Authentication Commands
Ethernet Switch CLI Reference Guide
108
4 Enables port authentication on ports 4 to 8.
5 Activates reauthentication on ports 4-8.
6 Specifies 1800 seconds as the interval for client reauthentication on ports 4-8.
This example configures the Switch in the following ways:
1 Enables the guest VLAN feature on port 8.
2 Puts port 8 in guest VLAN 200.
3 Sets host mode to multi-secure to have the Switch authenticate each client that connects
to port 8.
This example configures the Switch in the following ways:
1 Disables authentication on the Switch.
2 Disables re-authentication on ports 1, 3, 4, and 5.
3 Disables authentication on ports 1, 6, and 7.
sysname(config)# radius-server host 1 10.10.10.1 auth-port 1890 key
--> secretKey
sysname(config)# radius-server timeout 30
sysname(config)# port-access-authenticator
sysname(config)# port-access-authenticator 4-8
sysname(config)# port-access-authenticator 4-8 reauthenticate
sysname(config)# port-access-authenticator 4-8 reauth-period 1800
sysname(config)# port-access-authenticator 8 guest-vlan
sysname(config)# port-access-authenticator 8 guest-vlan 200
sysname(config)# port-access-authenticator 8 guest-vlan Host-mode Multi-
secure
sysname(config)# no port-access-authenticator
sysname(config)# no port-access-authenticator 1,3-5 reauthenticate
sysname(config)# no port-access-authenticator 1,6-7
