Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
166
This example shows global Switch LLDP statistics.
The following table describes the labels in this screen.
This example shows LLDP statistics on a port
802.1TLV Flags The 802.1 TLV Flags are (P) Port & Protocol VLAN ID, (V) Port VLAN ID,
(E) DCBX ETS Configuration, (F) DCBX PFC Configuration and (A) DCBX
Application Priority Configuration.
802.3TLV Flags The 802.3 TLV Flags are (L) Link Aggregation, (M) MAC/PHY
Configuration/Status, (F) Maximun Frame Size, and (P) Power Via MDI.
sysname# show lldp statistic
LLDP Global Statistic:
Neighbor Entries List Last Update: 0:00:00
New Neighbor Entries Count: 0
Neighbor Entries Deleted Count: 0
Neighbor Entries Dropped Count: 0
Neighbor Entries Ageout Count: 0
sysname#
Table 109 Switch LLDP statistics
LABEL DESCRIPTION
Neighbor Entries List Last Update This displays the time the LLDP database was last updated for
this and neighboring Switches.
New Neighbor Entries Count This displays the number of new neighbors added to the LLDP
database since the last update.
Neighbor Entries Deleted Count This displays the number of neighbors deleted from the LLDP
database since the last update.
Neighbor Entries Dropped Count This displays the number of neighbors dropped from the LLDP
database since the last update.
Neighbor Entries Ageout Count This displays the number of neighbors with expired TTLs since
the last update.
sysname# show lldp statistic interface port-channel 1
LLDP Port Statistic:
Local Port: 1
Frames Discarded: 0
Frames Invalid: 0
Frames Received: 0
Frames Sent: 0
TLVs Unrecognized: 0
TLVs Discarded: 0
Neighbor Ageouts: 0
sysname#
Table 108 LLDP settings on a port (continued)
LABEL DESCRIPTION
