Ethernet Switch CLI Reference Guide
269
CHAPTER 72
Stacking Commands
72.1 Overview
Stacking is directly connecting Switches to form a larger system that behaves as a single
Switch or a virtual chassis with increased port density.
The last two SFP ports of your Switch are dedicated for Switch stacking. These are the
Switches that support stacking at the time of writing.
Up to 8 Switches per stack are allowed.
You can manage each Switch in the stack from a master Switch using its web configurator or
console. Each Switch supports up to two stacking channels. Use the master Switch to assign a
‘slot ID’ for each ‘linecard’ non-master Switch. ‘Slot’ refers to a Switch in the the ‘virtual
chassis’ stack.
You can build a Switch stack using a ring or chain topology. In a ring topology, the last Switch
is connected to the first.
When you change modes, all configurations except user accounts, but
including running configuration, config01 and config02 will be erased and the
Switch will reboot with a new config01. Therefore, you should back up
previous configurations if you want to reload them later.
Table 169 Switch Stacking
MODELS WITH STACKING SUPPORT
XGS3700-24
XGS3700-24HP
XGS3700-48
XGS3700-48HP
