Chapter 60 PPPoE IA Commands
Ethernet Switch CLI Reference Guide
229
60.3 Command Examples
This is an example of how to enable and disable PPPoE IA on the Switch.
This is an example of how to enable and configure PPPoE IA for VLANs.
This is an example of how to set a PPPoE IA trust port.
This example is more advanced. It assumes a PPPoE IA client is connected to port 2 and a
PPPoE IA server is connected to port 5. If we want PPPoE IA to work, port 2 and port 5 must
be belong to the some VLAN and the PPPoE IA must be enabled globally and in this
corresponding VLAN. We also need to set port 5 as trust port. Then the last thing we need to
do is to decide which sub-options the received PADI, PADR, or PADT packet needs to carry.
Here, assume both circuit-id and remote-id should be carried.
sysname# configure
sysname(config)# pppoe intermediate-agent
sysname(config)# no pppoe intermediate-agent
sysname# configure
sysname(config)# pppoe intermediate-agent vlan 2
sysname(config)# pppoe intermediate-agent vlan 5,9,11
sysname(config)# pppoe intermediate-agent vlan 1 circuit-id
sysname(config)# pppoe intermediate-agent vlan 3,6 remote-id
sysname(config)# no pppoe intermediate-agent vlan 2-10
sysname(config)# no pppoe intermediate-agent vlan 1 circuit-id
sysname(config)# no pppoe intermediate-agent vlan 3,6 remote-id
sysname# configure
sysname(config)# interface port-channel 3
sysname(config-interface)# pppoe intermediate-agent trust
sysname(config-interface)# no pppoe intermediate-agent trust
sysname# configure
sysname(config)# vlan 2
sysname(config-vlan)# fixed 2,5
sysname(config-vlan)# untagged 2,5
sysname(config-vlan)# exit
sysname(config)# pppoe intermediate-agent
sysname(config)# pppoe intermediate-agent vlan 2
sysname(config)# interface port-channel 2
sysname(config-interface)# pvid 2
sysname(config-interface)#exit
sysname(config)# interface port-channel 5
sysname(config-interface)# pvid 2
sysname(config-interface)# pppoe intermediate-agent trust
sysname(config-interface)#exit
sysname(config)# pppoe intermediate-agent vlan 2 circuit-id
sysname(config)# pppoe intermediate-agent vlan 2 remote-id
