Zyxel XS3700-24 [332/371] The following table describes the labels in this screen
![Zyxel XS3700-24 [332/371] The following table describes the labels in this screen](/views2/1168986/page332/bg14c.png)
Chapter 93 Additional Commands
Ethernet Switch CLI Reference Guide
332
This example shows the current and recent CPU utilization.
The following table describes the labels in this screen.
suppressAlarm This field displays whether or not the alarm is inactive.
alarmLED This field displays whether or not the LED for this alarm is on.
sysname# show cpu-utilization
CPU usage status:
baseline 1715384 ticks
sec ticks util sec ticks util sec ticks util sec ticks util
--- ------- ------ --- ------- ------ --- ------- ------ --- -------
0 657543 61.67 1 255118 85.13 2 394329 77.01 3 620008 63.85
4 195580 88.60 5 791000 53.89 6 137625 91.98 7 508456 70.36
--------------------------------- SNIP ---------------------------------
Table 211 show cpu-utilization
LABEL DESCRIPTION
baseline This field displays the number of CPU clock cycles per second.
sec This field displays the historical interval.
Interval 0 is the time starting one second ago to the current instant.
Interval 1 is the time starting two seconds ago to one second ago.
Interval 2 is the time starting three seconds ago to two seconds ago.
ticks This field displays the number of CPU clock cycles the CPU was not used
during the interval.
util This field displays the CPU utilization during the interval.
util = [(baseline - ticks) / baseline] * 100
Table 210 show alarm-status (continued)
LABEL DESCRIPTION
