Chapter 29 IGMP Snooping Commands
Ethernet Switch CLI Reference Guide
114
show igmp-snooping group client <
[vlan <vlan-list>] [interface
port-channel <port-list>]
[multicast-group <group-address>]
>
Displays client IP information for the specified multicast
VLAN(s), port(s) and/or multicast group(s).
E3
show igmp-snooping group client
all
Displays client IP information for all multicast groups on
the Switch.
E3
show igmp-snooping group count Displays the total number of the multicast groups on the
Switch.
E3
show igmp-snooping group interface
port-channel <port-list>
Displays the multicast group(s) to which the specified
port(s) belongs.
E3
show igmp-snooping group interface
port-channel <port-list> count
Displays the number of the multicast group(s) to which the
specified port(s) belongs.
E3
show igmp-snooping group vlan
<vlan-list>
Displays the multicast group(s) for the specified multicast
VLAN(s).
E3
show igmp-snooping group vlan
<vlan-list> count
Displays the number of the multicast group(s) for the
specified multicast VLAN(s).
E3
show igmp-snooping querier Displays the IGMP query mode for the ports on the Switch. E 3
show igmp-snooping statistics
interface port-channel <port-list>
Displays the multicast statistics of the specified port(s). E 3
show igmp-snooping statistics
system
Displays the multicast statistics of the Switch. E 3
show igmp-snooping statistics vlan
<vlan-list>
Displays the multicast statistics of the specified multicast
VLAN(s).
E3
show multicast [vlan] Displays multicast status, including the port number, VLAN
ID and multicast group members on the Switch. Optionally,
displays the type of each multicast VLAN.
E3
Table 79 igmp-snooping vlan Command Summary
COMMAND DESCRIPTION M P
show igmp-snooping vlan Displays the VLANs on which IGMP snooping is enabled. E 3
igmp-snooping vlan mode
<auto|fixed>
Specifies how the VLANs on which the Switch snoops IGMP
packets are selected.
auto: The Switch learns multicast group membership on any
VLAN. See the User’s Guide for the maximum number of
VLANs the switch supports for IGMP snooping. The Switch
drops any IGMP control messages on other VLANs after it
reaches this maximum number (auto mode).
fixed: The Switch only learns multicast group membership
on specified VLAN(s). The Switch drops any IGMP control
messages for any unspecified VLANs (fixed mode). See the
User’s Guide for the maximum number of VLANs the switch
supports for IGMP snooping.
C13
Table 78 igmp-snooping Command Summary (continued)
COMMAND DESCRIPTION M P
