Chapter 3 Initial Setup
Ethernet Switch CLI Reference Guide
21
3.6 Looking at Basic System Information
Use this command to look at general system information about the Switch.
show system-information
This is illustrated in the following example.
See Chapter 93 on page 327 for more information about these attributes.
3.7 Looking at the Operating Configuration
Use this command to look at the current operating configuration.
show running-config
This is illustrated in the following example.
sysname# show system-information
Product Model : sysname
System Name : sysname
System Mode : Standalone
System Contact :
System Location :
System up Time : 98:26:28 (151f8939 ticks)
Ethernet Address : 00:19:cb:00:00:02
Bootbase Version : V1.02 | 08/27/2014
ZyNOS F/W Version : V4.20(AASS.0)b3 | 09/24/2014
Config Boot Image : 1
Current Boot Image : 1
RomRasSize : 8336318
sysname#
sysname# show running-config
Building configuration...
Current configuration:
vlan 1
name 1
normal ""
fixed 1-9
forbidden ""
untagged 1-9
ip address default-management 172.16.37.206 255.255.255.0
ip address default-gateway 172.16.37.254
exit
