Ethernet Switch CLI Reference Guide
264
CHAPTER 71
SNMP Server Commands
Use these commands to configure SNMP on the Switch.
71.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 166 snmp-server User-input Values
COMMAND DESCRIPTION
property 1-32 alphanumeric characters
options aaa: authentication, authorization, accounting.
interface: linkup, linkdown, autonegotiation, lldp, transceiver-
ddm.
ip: ping, traceroute.
switch: stp, mactable, rmon, cfm.
system: coldstart, warmstart, fanspeed, temperature, voltage,
reset, timesync, intrusionlock, loopguard, errdisable, poe.
Table 167 snmp-server Command Summary
COMMAND DESCRIPTION M P
show snmp-server Displays SNMP settings. E 3
snmp-server <[contact <system-
contact>] [location <system-
location>]>
Sets the geographic location and the name of the person in
charge of this Switch.
system-contact: 1-32 English keyboard characters;
spaces are allowed.
system-location: 1-32 English keyboard characters;
spaces are allowed.
C13
snmp-server version
<v2c|v3|v3v2c>
Sets the SNMP version to use for communication with the
SNMP manager.
C13
snmp-server get-community
[cipher] <property>
Sets the get community. Only for SNMPv2c or lower.
cipher: inform the Switch that the string after the word
"cipher" is an encrypted secret. This is used in password
encryption. To encrypt the password, use the password
encryption command.
C13
snmp-server set-community
[cipher] <property>
Sets the set community. Only for SNMPv2c or lower.
cipher: inform the Switch that the string after the word
"cipher" is an encrypted secret. This is used in password
encryption. To encrypt the password, use the password
encryption command.
C13
