Chapter 47 MAC Pinning Commands
Ethernet Switch CLI Reference Guide
188
47.2 Command Examples
This example enables MAC pinning on the Switch and port 3. It also shows the MAC pinning
status.
sysname(config)# interface port-channel 3
sysname(config-interface)# mac-pinning
sysname(config-interface)# exit
sysname(config)# exit
sysname# show mac-pinning
MAC Pinning Status: Enable
Port Active
---- --------
1 No
2 No
3 Yes
4 No
5 No
6 No
7 No
8 No
9 No
10 No
11 No
12 No
13 No
14 No
15 No
16 No
17 No
18 No
19 No
20 No
21 No
22 No
23 No
24 No
25 No
26 No
27 No
28 No
sysname#
