![Zyxel XS3700-24 [268/371] Command examples](/views2/1168986/page268/bg10c.png)
Chapter 71 SNMP Server Commands
Ethernet Switch CLI Reference Guide
268
71.2 Command Examples
This example sets the Switch to not send the linkup and linkdown traps received on port 3 to
the SNMP manager.
This example shows you how to display the SNMP information on the Switch.
This example shows you how to display all SNMP user information on the Switch.
sysname# configure
sysname(config)# interface port-channel 3
sysname(config-interface)# no snmp trap linkup linkdown
sysname# show snmp-server
[General Setting]
SNMP Version : v2c
Get Community : public
Set Community : public
Trap Community : public
[ Trap Destination ]
Index Version IP Port Username
----- ------- ------------ ---- --------
1 v2c 0.0.0.0 162
2 v2c 0.0.0.0 162
3 v2c 0.0.0.0 162
4 v2c 0.0.0.0 162
sysname# show snmp-server user
[ User Information ]
Index Name SecurityLevel GroupName
----- ------ ------------- --------------
1 admin noauth admin
